XJ flotation machine

Effective Volume: 0.37-8m³

Production Capacity: 0.2-8m³/min

Applications: Non-ferrous and ferrous metals, coal fluorite, talc, etc.

Product Description: This flotation machine uses a V-belt drive driven by an electric motor to rotate the impeller, generating a centrifugal force that creates negative pressure. This draws in sufficient air to mix with the slurry while also agitating the slurry and mixing it with the reagents. This simultaneously refines the foam, allowing the minerals to adhere to the foam and float to the surface of the slurry, forming a mineralized foam. The liquid level is controlled by adjusting the gate height.

I. Product Introduction

The XJ flotation cell, a model introduced from the former Soviet Union, has a long history and is widely used. It is still widely used in mineral processing operations. The flotation cell uses a V-belt drive driven by an electric motor to rotate the impeller, generating centrifugal force and negative pressure. This not only draws in sufficient air to mix with the slurry, but also stirs the slurry and reagents, while simultaneously refining the foam, causing the minerals to adhere to the foam and float to the surface of the slurry, forming a mineralized foam. Adjusting the gate height controls the liquid level, allowing the useful foam to be scraped away by the scraper.

II. Applications

The XJ flotation cell can be used for roughing, concentrating, scavenging, and reverse separation of nonferrous metals, ferrous metals, and non-metallic ores.

The XJ flotation cell primarily separates metals such as gold, silver, copper, iron, lead, zinc, molybdenum, nickel, and aluminum. It can also be used for roughing and concentrating ferrous and non-metallic ores.

Working Principle

The XJ flotation machine uses a triangular motor drive to rotate the impeller, generating a centrifugal force that creates negative pressure. This draws in sufficient air to mix with the slurry while also agitating the slurry and mixing it with the reagents. This simultaneously refines the foam, causing minerals to adhere to the foam and float to the surface of the slurry, forming a mineralized foam. The liquid level is controlled by adjusting the gate height, allowing the useful foam to be scraped off by the scraper.
