- Disc nano grinder
The LSM-A universal disc ultra-fine sand mill features a mixing shaft that drives the sanding media throughout the sanding drum. A high-efficiency centrifugal separation system separates the product from the sanding media
Disc nano grinder
The LSM-A universal disc ultra-fine sand mill features a mixing shaft that drives the sanding media throughout the sanding drum. A high-efficiency centrifugal separation system separates the product from the sanding media, ensuring the machine's operation even with highly viscous products. Depending on the specific requirements of the product, the machine can be designed for various materials (e.g., polyurethane, rubber, ceramics, cold urethane, rubber, ceramics, freeze casting, and wear-resistant steel).
Product Details
LSM-A Series Universal Nano Grinder: Single-Pass Universal Disc Grinder
Suitable Fineness: 20μm - 5μm
Grinding Media Size: ≥ 0.9mm
This machine is flexible, easy to clean, and maintain, making it suitable for grinding small and multi-batch products.
Technical data
| Model | Experimental | Mass production level | |||||||
| LSM-0.3L | LSM-1.4L | LSM-5L | LSM-15L | LSM-B20L | LSM-B20L | LSM-B30L | LSM-B50L | LSM-B60L | |
| Amplification factor[-] | - | - | 0.08 | 0.2 | 0.5 | 2 | 4 | 8 | |
| Sanding barrel capacity[l] | 0.6 | 0.6 | 1 | 6 | 10 | 30 | 60 | 150 | 300 |
| Processing batch[Vh] | 0.3-1 | 1-2 | 2-10 | 100-600 | 100-500 | 500-2000 | >2000 | >4000 | >7000 |
| Sanding media[mm] | 10-50 | 100-300 | 180-380 | 40-200 | 100-500 | 500-2500 | 1000-6000 | 2000-1500 | 5000-20000 |
| power[kw] | 0.75 | 2.2 | 3.7 | 15 | 22 | 45 | 75 | 160-200 | 315 |
Design Concept
Technology—Setting New Standards in Dispersion and Fine Grinding Technology
Universal Nano Grinder LSM-A Series Single-Pass Process
Design Concept—Suppressing Energy Loss and Providing High-Flow Separation for Your Benefits
Applications
LSM-A Series Universal Disc Nano Grinder—High-Quality Production, Wide Applications.
Applications: Water-soluble, oil-soluble, and non-polluting products, suitable for machinery and engineering applications across various industries and applications.
The Grinding and Dispersing Division provides equipment and engineering services for the following industries and applications.
● Carbon Black
● Automotive Topcoats and Primers
● Marine Paints, Electrophoretic Coatings, Metal Paints, and Coil Coatings
● Water-Based and Solvent-Based Wood Coatings
● Pesticide Suspension Concentrates
● Latex Paints, Sulfur, and Zinc Oxide
● Gravure and Flexographic Inks
● Papermaking, Heavy Calcium Carbonate, and Fillers
● Leather
