- Mineral powder rotary dryer
Our newly developed mineral powder dryer features reliable operation, high flexibility, adaptability, and a high throughput. Also known as a rotary drum dryer, this dryer is generally suitable for granular materials, but can also be used to partially incorporate materials to dry sticky, pasty materials, or materials with high moisture content.
Mineral powder rotary dryer
Our newly developed mineral powder dryer features reliable operation, high flexibility, adaptability, and a high throughput. Also known as a rotary drum dryer, this dryer is generally suitable for granular materials, but can also be used to partially incorporate materials to dry sticky, pasty materials, or materials with high moisture content.
[Feed Size]: <= 50mm [Processing Capacity]: 1.5-40t/h
[Applications]: Suitable for drying materials in industries such as cement, mining, building materials, chemicals, grain, and compound fertilizer production.
[Applicable Materials]: Suitable for various metal and non-metallic mineral powders, including slag.
Principle of working
Powdered or granular mineral powder is conveyed by a belt conveyor to a feeder, which then transports it to the drying drum. The powder is evenly dispersed and fully exposed to the hot air by the uniformly distributed scrapers within the drying drum, achieving the purpose of heat and mass transfer. The dried mineral powder is discharged from the drum terminal through a discharger and discharged by a belt discharger, completing the drying process.
Data
Model | Angle（%） | Rotation speed | temperature | Power | capacity（t/h） | weight |
Ф800x8000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.0 | 3.5 |
Ф800x10000 | 3-5 | 3-8 | ≤700 | 4 | 0.8-2.5 | 4.5 |
Ф1000x10000 | 3-5 | 3-8 | ≤700 | 5.5 | 1.0-3.5 | 5.6 |
Ф1200x10000 | 3-5 | 3-8 | ≤700 | 7.5 | 1.8-5 | 14.5 |
Ф1200x12000 | 3-5 | 3-8 | ≤700 | 11 | 2-6 | 14.8 |
Ф1500x12000 | 3-5 | 2-6 | ≤800 | 15 | 3.5-9 | 17.8 |
Ф1800x12000 | 3-5 | 2-6 | ≤800 | 18 | 5-12 | 25 |
Ф2200x12000 | 3-5 | 1.5-6 | ≤800 | 18.5 | 6-15 | 33 |
Ф2200x18000 | 3-5 | 1.5-6 | ≤800 | 22 | 10-18 | 53.8 |
Ф2200x20000 | 3-5 | 1.5-6 | ≤800 | 30 | 12-20 | 56 |
Ф2400x20000 | 3-5 | 1.5-5 | ≤800 | 37 | 18-30 | 60 |
Ф3000x20000 | 3-5 | 1.5-5 | ≤800 | 55 | 25-35 | 78 |
Ф3000x25000 | 3-5 | 1.5-5 | ≤800 | 75 | 32-40 | 104.9 |
